Pitched roof mounting

/Asphalt tile roof flashing L feet

Asphalt tile roof flashing L feet

Asphalt tile roof flashing L feet is designed for cost-effective, one-bolt installation onto existing composition/asphalt shingle roofs.
  • Item No.:

    SIC-FL
  • Brand:

    SIC SOLAR
  • Material:

    AL6005-T5 & SUS304
  • Warranty:

    10 years and 25 years service time
  • Wind Load:

    <60M/S
  • Snow Load:

    <1.4KN/M2
  • product details

L-Mount and aluminum flashing



SIC Asphalt roof solar racking is designed for asphalt single roof, the flashing plate with raised tapered hole, together with rubber pad can perfectly cooperate with L feet, which has good waterproof founction.

The flashing material is Aluminum 6005-T5, and the screw will depend on the steel beam or wooden beam.


Aluminum flashing kit



Category: Pitched roof mounting


Installation Site

Roof

Wind Load

<60M/S

Snow Load

<1.4KN/M2

Material

Aluminum 6005-T5 or SUS304

Color

Natural or Customized

Anticorrosive

Anodized aluminum & stainless steel

Warranty

10 years and 25 years service time




       L-Mount Flashing

L-Mount Flashing










Advantages as follow:

☆ Easy Installation--L feet will be fixed on steel or wooden purlin directly.

☆ Great Flexibility--The flashing direction can be adjusted according to the single roof.

☆ Waterproofing--The flashing and rubber pad can perfectly prevent water.

☆ Pre-assembled components  – highly save the labor cost at your installation site.


Related certificate

Strength Analysis report -- mountings will be test to meet your target strength, Like wind speed and snow load.



Package for solar L feet bracket
