Solar Triangle Flat Roof Mounting System

Click here to learn more triangle frame mount

1️⃣ Plan the Layout: Check the roof structure and available space, determine the required tilt angle, and mark the positions of the triangular brackets.

2️⃣ Secure the Base: Select a suitable fixing method based on the roof type and structural design. Ballast may be used where appropriate, while any temporary supports must be suitable for the installation conditions.

3️⃣ Install the Triangular Brackets: Position and secure the brackets and braces at the specified intervals. For taller structures, additional support members may be required.

4️⃣ Attach the Rails: Fix the horizontal aluminum rails to the triangular brackets using compatible clamps or stainless steel bolts.

5️⃣ Mount the Solar Panels: Position the panels on the rails and secure them with suitable mid and end clamps.

6️⃣ Complete the Final Checks: Check panel alignment, fastener tightness, structural stability, grounding, and electrical connections before commissioning.

☆ Flexible Tilt Options: Fixed-angle designs and customized options are available to suit different project requirements.

☆ Easy Installation: Pre-assembled components help reduce on-site assembly time and simplify installation.

☆ Weather Resistance: The structure can be assessed and designed to meet project-specific wind and snow load requirements.

☆ Durable Construction: The system comes with a stated 10-year warranty and 25-year expected service life, subject to the manufacturer's terms and installation conditions.

☆ Customizable Design: Bracket dimensions, tilt angles, rail configurations, and fixing methods can be adapted to project needs.

Related Certificates

☆ Strength Analysis Report: Supports the assessment of mounting system performance under specified wind and snow loads.

☆ Aluminum Quality Certificate: Provides the material composition details for AL6005-T5 aluminum alloy.

Q1: Can the tilt angle be customized?
Yes, depending on the model. Confirm the available tilt range with the manufacturer based on your project requirements.

Q2: Can the system withstand strong winds and heavy snow?
Performance depends on the overall design, fixing strength, bracket spacing, roof capacity, and local wind and snow loads. Project-specific structural calculations are essential.

Q3: Which solar panels are compatible with this system?
It can support compatible framed PV modules when their dimensions, clamp type, rail arrangement, and load requirements match the mounting design.

Q4: Can the Solar Triangle Flat Roof Mounting System be customized?
Depending on the manufacturer, the tilt angle, bracket dimensions, materials, rail lengths, and fixing configuration can be customized to meet project requirements.
