Solar Rail Splice for RH2 Rail

Solar Rail Splice for RH2 Rail is designed to connect two RH2 mounting rails, extending the rail length while maintaining a stable, aligned structure for solar panels.

Brand:

SIC SOLAR

Item NO.:

SIC-RS-RH2

Product Origin:

Fujian, China

Color:

NATURE

Shipping Port:

Xiamen port

Installation Site:

Solar Rail

Color:

Can be customized

Material:

AL6005-T5

Warranty:

10 years and 25 years service time

Length:

Can be customized

Thickness:

Can be customized

Wind Load:

<60M/S

Snow Load:

<1.4KN/M²

Components Technical Details Installation Guide Package Advantage FAQ

Click here to learn more splices.

Photovoltaic rail splice bracket

Installation Site	Solar Rail
Wind Load	<60M/S
Snow Load	<1.4KN/M²
Material	AL6005-T5
Color	Natural or Customized
Anticorrosive	Anodized aluminum
Warranty	10 years and 25 years service time

1️⃣ Check Compatibility: Confirm that the splice matches the RH2 rail profile and connection requirements.

2️⃣ Prepare the Rails: Place the rail sections on a stable surface and clean their ends to remove dirt or debris.

3️⃣ Insert the Splice: Fit the splice into the designated channel or connection area according to the product design.

4️⃣ Align the Rails: Bring the two rail sections together and check that they are straight and properly aligned.

5️⃣ Secure the Connection: Install and tighten the specified fasteners according to the manufacturer's instructions.

6️⃣ Inspect the Joint: Check the splice position, rail alignment, and fastener tightness before mounting the solar panels.

Aluminium profile connector

☆ Flexible Rail Extension: Connects compatible RH2 rail sections to create longer mounting runs.

☆ Easy Installation: The straightforward connection design helps simplify on-site assembly.

☆ Durable Aluminum Construction: Made from AL6005-T5 aluminum alloy, with a stated 10-year warranty and 25-year expected service life, subject to the manufacturer's terms and installation conditions.

☆ Ready-to-Use Design: Helps reduce on-site preparation and installation labor.

Related Certificate

☆ Aluminum Quality Certificate: Provides the material composition details for AL6005-T5 aluminum alloy.

Q1: Is this splice compatible with all solar rails?
No. It is designed for the RH2 rail profile. Compatibility with other rail types should be confirmed before use.

Q2: Can the splice be used to extend solar mounting rails?
Yes. It connects compatible rail sections to extend the mounting layout, provided this connection method is approved for the system design.

Q3: How can I ensure the connection is secure?
Use the correct splice and fasteners, align the rails carefully, and tighten all connections according to the manufacturer's instructions.

Q4: What should I check before purchasing?
Confirm the RH2 rail model, splice dimensions, material, fastener requirements, order quantity, and compatibility with your mounting system.
