Solar panel wall mounting systems

Wall tilt frame system is developed for wall, which can help our customers to have more choose to install solar panel.
  • Item No.:

    SIC-TM
  • Installation Site:

    Wall or flat concrete roof
  • Color:

    Nature
  • Material:

    Aluminum or galvanized steel
  • Warranty:

    10 years and 25 years service time
  • Wind Load:

    <60M/S
  • Snow Load:

    <1.4KN/M2
  • product details

Solar panel wall mounting systems



Wall PV mounting solution is an economical mounting type for panel installation. It can be easily installed on wall in customized angle.

SIC solar develops different mounting series to meet demands of the panel facade installation.The panel will be fixed on wall tightly, which can withstand high wind speed. With the mounting installed back of panels, it looks very concise and pretty.


Solar panel mounting frame



Category: Flat roof mounting


Installation Site

Roof or Wall

Wind Load

<60M/S

Snow Load

<1.4KN/M2

Material

Aluminum 6005-T5 & Stainless Steel 304

Color

Natural or Customized

Anticorrosive

Anodized aluminum & stainless steel

Warranty

10 years and 25 years service time



               Wall mounted solar panels



Solar awning racking


1. Put fixed wall tilt frame on the wall surface.

2. Fix the rail on the fixedwall tilt frame.

3. Fix the mid clamp between panels, end clamp on the panel edge.

4. Finished.



☆ Easy to use - Highly pre-assembled components make the installation more quickly and easily.

☆  Safety - The whole structure have been strictly tested to stand up to the extreme weather

☆ High Quality - Structure have been strictly controlled to ensure 10 years warranty & 25 Years lifetime.


Related certificate

Strength Analysis report -- mountings will be test to meet your target strength, Like wind speed and snow load.Aluminum quality certificate -- AL6005-T5 composition list



Triangle frames could be packed into cartons with plywood pallet. Steel pallet could be offered if needed.


package for solar panel mount triangle frame
