Pitched roof mounting

/Solar panel mount for trapezoidal metal sheet

Solar panel mount for trapezoidal metal sheet

SIC aluminum short rail can be used on trapezoidal sheet metal roof, using short rail can help customers to save more cost.
  • Item No.:

    SIC-TC-15
  • Installation Site:

    Roof
  • Color:

    Nature
  • Material:

    AL6005-T5
  • Warranty:

    10 years and 25 years service time
  • Wind Load:

    <60M/S
  • Snow Load:

    <1.4KN/M2
  • product details

Metal roof solar racking systems



Metal roof aluminum short rail system can help our customer to save more material cost and installation time. Using Self-tapping screws fix the SIC-TC-15 clamp directly to the trapezoidal sheet.


Metal roof solar panel mounting bracket



Category: Pitched roof mounting


Installation Site

Roof

Wind Load

<60M/S

Snow Load

<1.4KN/M2

Material

Aluminum 6005-T5

Color

Natural or Customized

Anticorrosive

Anodized aluminum & stainless steel

Warranty

10 years and 25 years service time



Mini rail solar racking system for metal roof


   short rail solar roof mounting kit



Advantages as follow:
☆ Easy to use - Only 3 components, Save labor cost at the installation site.
☆ Short rail array could be customized according to your roof size.
☆ EPDM rubber can be effective waterproofing.

☆ Best aluminum profile Ensure 10 years warranty and 25 years service time.


Related Certificate

Our SGS Certificate for screw material -- SUS304 Strength Analysis report -- mountings will be test to meet your target strength, Like wind speed and snow load.



package for short rail solar mounting system
